10ft T14 Stainless Steel Tank Container
10ft T14 Stainless Steel Tank Container Introduction
The 10ft T14 Stainless Steel Tank Container is designed to comply with the requirements of IMDG Code, aiming at transportation of liquid and powder on the road, rail, ship, trailer, etc. This stainless steel tank is used for storing and transporting bulk liquids and powders.
Standard: IMDG T14, ADR/RID, CFR49, TIR, CSC
Max Cargo Temperature: -40 to +65 degree Celsius
Certificate: CSC certificate like GL/LR/BV/ABS
All tanks are of the highest quality design and construction and conform strictly to the latest international approvals.
10ft T14 Stainless Steel Tank Container Specification
| Tank Type: | 10’ ISO full-frame collar tank, Type UN portable Tank Type T14; no-insulated, no-steam heated, top side rails fitted, prepared for lining |
| Frame Dimensions: | 2991mm×2438mm×2591mm |
| Capacity: | 7,000 Litres +/- 2% |
| M.G.W.: | 16,000 kg |
| Tare (est.): | 2,450 kg +/- 5% |
| Max Payload: | 13,550 kg |
| Working Pressure: | 4 Bar |
| Test Pressure: | 6 Bar |
| Design Temp: | -40°C to +65°C |
| Vessel Material: | ASTM A240 304 stainless steel, hot rolled or equivalent |
| Shell Thickness: | 5mm nominal |
| Ends Thickness(B.F): | 6mm nominal |
| Corrosion Allowance: | NIL |
| Lining Material: | Supplied by the buyer |
| Frame Material: | GB/T 1591-Q345D |
| Frame to Shell: | 304 stainless steel |
| Corner castings: | ISO 1161 – 8 off |
| Vessel Design Code: | ASME VIII Div 1 where applicable |
| Radiography: | Shell: ASME Spot Ends: ASME Full |
| Inspection Agency: | LR |
| Cargo carried: | See dangerous cargo lists for UN Portable T14 tank and compatible with the tank lining material |
| Stacking | Each container is approved for 9 high stacking |
| Design Approvals: | IMDG T14,CFR 49, ADR/RID, CSC, TIR, ISO |
Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. Subject to change without prior notice. For the actual specification, please check with us when order placed. Classification certification like CCS, DNV, BV, LR, NK, KR, RS shall be provided upon request.
