Moorfast Anchor

Material: Carbon Steel
Weight: 450kg~45,000kg
Finish: Blacking Bitumen Painting
Class Certificate: ABS, LR, BV, DNV, GL, NK, KR, IRS, and CCS
Application: for offshore platform mooring application.

Moorfast Anchor

Moorfast Anchor Introduction

The Moorfast Anchor is an offshore anchor. It is designed with enlarged flukes and tripping palms for quick and stable penetration in sand or mud bottoms. The Moorfast anchor head and shank are manufactured of ASTM A27-80 Grade 70-40 cast steel or equivalent. The stock can be made of the same material or rolled bar stock, the material used for forging the shackle body. The shackle pin is alloy-steel rolled bar stock.

The anchors are of high quality and good stability. The weight of the Anchor is 450kgs-45,000kgs.

The Moorefast Anchor can be supplied with certification from any of the major classification societies.

Moorfast Anchor Drawing

Moorfast Anchor Drawing

Moorfast Anchor Drawing

Moorfast Anchor Specification

anchor weight A B C D E F
Kg mm mm mm mm mm mm
450 1549 1905 940 645 483 51
1350 2235 2769 1372 930 686 76
2700 2565 3632 1549 1067 787 89
3600 3091 3886 1905 1295 965 89
4500 3327 3988 2032 1397 1041 102
5400 3531 4242 2159 1473 1092 102
6300 3734 4496 2286 1549 1143 102
7200 3886 4750 2388 1626 1219 115
9000 4166 4978 2591 1853 1295 115
13500 4801 5512 2997 2007 1499 127
18000 5436 6299 3226 2184 1600 127
22500 5639 6528 3353 2261 1676 153
27000 5893 6883 3556 2413 1778 153
31500 6198 6960 3734 2540 1854 153
36000 6477 7569 3912 2667 1956 165
40500 6756 7874 4064 2769 2031 165
45000 6985 8128 4216 2870 2108 178

Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. Subject to change without prior notice. For the actual specification, please check with us when order placed. Classification certification like CCS, DNV, BV, LR, NK, KR, RS shall be provided upon request.
