Type U Rubber Fender

Material: Rubber, EPDM
Type: Type U
Class Certificate: ABS, LR, BV, DNV, GL, NK, KR, IRS, and CCS
Application: used to absorb the berthing energy during mooring or berthing so as to protect the ship and the dock from being damaged.

Type U Rubber Fender

Type U Rubber Fender Introduction

The Type U rubber fender is typically mounted to a dock or a ship to counteract the collision force between the dock and the ship generated during mooring and berthing, thus preventing ships and docks from being damaged.

This type of rubber fender features high energy absorption performance and proper reaction force. with high strength construction parts, it offers long service life. It is easy for replacement.

The Type U Marine Rubber Fender can be supplied with certification from any of the major classification societies.

Length: 850mm to 2500mm

Width: 150mm to 650mm

Height: 100mm to 500mm

The thickness of material: 35mm

Type U Rubber Fender Drawing

Type U Rubber Fender Construction

Type U Rubber Fender Construction

Type U Rubber Fender Spec

Specification H L h B B1 C Q e f d g
U300H*1500L 300 1500 35 540 430 150 600 60 90 32 80
U300H*900L 300 900 35 540 430 150 600 60 90 32 80

Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All specifications are subject to change without prior notice. All pictures shown are for illustration purposes only. Actual product may vary. Classification certification like CCS, DNV, BV, LR, NK, KR, RS shall be provided upon request.
