20ft T50 Anhydrous Ammonia tank container

Capacity: 10,900L to 26,000L
Working Pressure: 21Bar;
Certificate; CCS/LR/BV
Design Code: ASME VIII Div 1
Design Approvals: IMDG T3, ADR/RID, CSC, TIR, ISO, UIC, US/UK DOT

20ft T50 Anhydrous Ammonia tank container

20ft T50 Anhydrous Ammonia tank container Introduction

The Anhydrous Ammonia tank container is designed to comply with the requirements of IMDG Code, aiming at transportation and stock Anhydrous Ammonia. This Liquid chlorine Tank is made of stainless steel or carbon steel with glycol electrical heating system.


Design Temperature:-40 degree Celsius to +55 degree Celsius

Certificate: CSC certificate like GL/LR/BV/ABS

All tanks are of the highest quality design and construction and conform strictly to the latest international approvals.

20ft T50 Anhydrous Ammonia tank container Specification

Tank Type: 20’ ISO full-frame collar tank, Type UN Portable Tank T50 With Sunshield, top side rails fitted
Frame Dimensions: 20’ x 8’ x 8’6”
M.G.W.: 32,700 kg
Tare (est.): 7,700 kgs +/- 3%
Max Payload: 25,000 kgs
MAWP: 21 Bar
Test Pressure: 27.3 Bar
Max. Allowable Vacuum 1.0 Bar
Design Temp: -40°C to +55°C
Vessel Material: ASME SA612
Shell Thickness: 16mm Nominal
Ends Thickness: 18mm Nominal
Corrosion Allowance 0 mm
Frame Material: GB/T 1591-94-Q345D
Frame to Shell: Q345R
Corner castings: ISO 1161 – 8 off
Vessel Design Code: ASME VⅢDiv,1
Cargo carried: R22 (UN 1018) , R134a(UN 3159)
Radiography: RT(X-ray) : 100% all longitudinal and circumferential butt welds
Inspection Agency: Lloyd’s Register
Design Approvals: IMDG T50 , ADR/RID, CSC, TC, TIR, ISO, UIC

Please note that the above specifications are “general specifications” that pertain to the majority of our products. These specifications should only be used for general, informational purposes. The measurement/size of the goods delivered may be different from the data in the above table, please check with us when order placed.
