2W W Series Oil and Gas Mixed Transfer Twin screw Pump
2W W Series Oil and Gas Mixed Transfer Twin screw Pump Introduction
2W W series twin screw pump is researched and developed with the regulations of the national standard GB11035-89. 2W W series twin screw pump with a heating jacket can transport all kinds of clean or containing solid granule of low viscosity and high viscosity medium (general particle diameter less than 0.12-0.2 mm).
1、The highest pressure 4.0MPa
2、Capacity range 1～1000m3/h
3、Temperature range -20～120℃
4、The viscosity of the medium 1～3000mm2/s, when lower the speed of the rotation it can be up to106mm2/s
The viscosity of the medium will largely influence the twin screw pump, the nominal discharge of the pump means the discharge under the certain viscosity condition. in order to ensure the pump to work on the high-efficiency working condition, when the test is not enough, we suggest selecting the speed of the rotation according to the following viscosity.
|The viscosity of the medium cSt||Speed r/min|
When the viscosity of the medium is higher, the customer should contact the manufacturer for the speed of rotation and motor power.
1、Oil field: Used as the multiphase mixed transporting pump and crude oil transporting pump and the like which can transport oil, gas, water, tiny solid particle.
2、Shipbuilding: Using as marine loading pump, ballast pump an sewage treatment pump, main machine lubricating pump and fuel oil pump.
3、Petrochemical industry: Using as loading and transporting pump which can transport all kinds of resin, pigment, paraffin-wax, paint, printing ink, emulsoid, all kinds of oil crude oil, heavy oil and the like.
4、Power plant: Using as heavy oil, crude oil transporting pump, main machine lubricating pump.
5、Food industry: Using as transporting pump which can transport alcohol, honey, syrup, juice, milk, slurry oil.
