AWS A5.9 ER316L Stainless Steel TIG Welding Wire

Material: Stainless Steel TIG Welding Wire
AWS Specification: AWS A5.9 ER316L
Diameter: 0.8/1.0/1.2/1.6/2.0/2.4/3.2mm
Welding Current: DCEP
Application: Primarily used for welding low carbon molybdenum bearing austenitic stainless steels.

AWS A5.9 ER316L Stainless Steel TIG Welding Wire

AWS A5.9 ER316L Stainless Steel TIG Welding Wire Application

AWS A5.9 ER316L Stainless Steel TIG Welding Wire is suitable for petrochemical industry, pressure vessel, cryogenic tank, fertilizer, urea, food machinery, and other industries to weld 18%Cr-12%Ni-2%Mo stainless steel (e.g. SUS316L).

ER316L main component is 18Cr-12Ni-2Mo; it is Stainless steel TIG welding wire. The metal of weld bead has excellent corrosion resistance, heat resistance and excellent crack resistance it has good resistance for acetic acid, sulfuric acid, phosphoric acid and salt corrosion because it contains Molybdenum. USES: It is widely used in petrochemical, chemical fertilizer equipment such as 06Cr17Ni12Mo2 (SUS 316) and other materials of welding. It can be used for welding without heat treatment of high Cr steel and various steel welding as well.

ER316L is primarily used for welding low carbon molybdenum-bearing austenitic alloys. This filler metal has the same analysis as ER316, except that the carbon content is limited to a maximum of 0.03% in order to reduce the possibility of formation of intergranular carbide precipitation. This low carbon alloy is not as strong at elevated temperatures as ER 316H

Features:
1. Good performance in corrosion resistance makes welding quality higher.
2. Good coil-forming ability
3. High elasticity and high fatigue resistance
4. Strong corrosion resistance against exposure to the toughest atmosphere

AWSA5.9 ER316L
A5.9M ER316L
EN IS014343-A:W(19 12 3L)
EN IS014343-B:SS316L
JISZ3321 YS316L

Certifications: ABS、CCS、DNV/GL、LR、CE、JIS

AWS A5.9 ER316L Stainless Steel TIG Welding Wire Chemical Composition

wt% C Mn Si Cr Ni Mo P S Cu
YB/T 0.022 1-2.5 0.65 18-20 11-14 2-3 0.03 0.03 0.75
AWS 0.022 1-2.5 0.65 18-20 11-14 2-3 0.03 0.03 0.75
Typical Value 0.018 1.98 0.51 18.67 11.81 2.21 0.021 0.013 0.06

AWS A5.9 ER316L Stainless Steel TIG Welding Wire Mechanical Properties

Typical ER316/ER316L Mechanical Properties (as welded)
Yield Strength 58 ksi
Tensile Strength 86 ksi
Elongation 36% min

Available Diameters & Operating Range

0.035″ 60-90A
0.045″ 80-110A
1/16″ 90-130A
3/32″ 120-175A
1/8″ 150-220A
5/32″ 170-350A

Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All specifications are subject to change without prior notice. All pictures shown are for illustration purposes only. Actual product may vary.
