BCB Series Inner Meshing Cycloid Gear Oil Pump

Type: Rotary Gear Pump
Material: Cast Iron /Stainless steel
Pressure: 1.6Mpa
Speed: 910-1440r/min
Capacity: 0.6-15m3/h
Application: booster pump in fuel transfer system, or an injection pump in the fuel system, and a lubricating pump in all industries.

BCB Series Inner Meshing Cycloid Gear Oil Pump

BCB Series Inner Meshing Cycloid Gear Oil Pump Application

BCB Series inner meshing cycloid gear oil pump is with compacted structure, stable revolving, high efficiency and long service life. It works as a booster pump in fuel transfer system, a transmission, booster or an injection pump in the fuel system, and a lubricating pump in all industries.

The BCB Series inner meshing cycloid gear oil pump is suitable for the transportation of lube or liquid that is similar in nature. The limitation of the liquid is that it should be without solid particle and fiber, non-corrosive, below 150°C (302°F) and viscosity between 5~1500c.s.t.

BCB Series inner meshing cycloid gear oil pump Specification

Model Capacity Pressure Suction Caliber Motor
(L/min) (m3/h) (MPa) (m) (Inch) Speed
(r/min)
Power
(KW)
Model
BCB-10/1.6 10 0.6 1.6 5 G3/8″ 1390 0.55 Y80M1-4
BCB-16/1.6 16 0.96 1.6 5 G3/4″ 1390 0.75 Y80M2-4
BCB-20/1.6 20 1.2 1.6 5 G3/4″ 1400 1.1 Y90S-4
BCB-25/1.6 25 1.5 1.6 5 G3/4″ 1400 1.1 Y90S-4
BCB-32/1.6 32 2 1.6 5 G1″ 1400 1.5 Y90L-4
BCB-40/1.6 40 2.4 1.6 5 G1″ 1420 2.2 Y100L1-4
BCB-50/1.6 50 3 1.6 5 G1″ 1420 2.2 Y100L1-4
BCB-63/1.6 63 3.8 1.6 5 G1″ 1420 3 Y100L2-4
BCB-80/1.6 80 4.8 1.6 5 G1  1/2″ 1420 3 Y100L2-4
BCB-100/1.6 100 6 1.6 5 G1  1/2″ 1440 4 Y112M-4
BCB-125/1.6 125 7.5 1.6 5 G1  1/2″ 1440 5.5 Y132S-4
BCB-160/1.6 160 9.6 1.6 4.5 G2″ 1440 5.5 Y132S-4
BCB-200/1.6 200 12 1.6 4.5 G2″ 1440 7.5 Y132S-4
BCB-250/1.6 250 15 1.6 4.5 G2″ 1440 7.5 Y132S-4

Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. Subject to change without prior notice. For the actual specification, please check with us when order placed. Classification certification like CCS, DNV, BV, LR, NK, KR, RS shall be provided upon request.
