CQW Type Marine Magnetic Vortex Submersible Sewage Pump
CQW Type Marine Magnetic Vortex Submersible Sewage Pump Application
CQW Type Marine Magnetic Vortex Submersible Sewage Pump energy saving effect is remarkable, winding, no blockage prevention, automatic installation and automatic control, etc. Solid particles in the lining and long fiber waste, has a unique effect. For transport of urban sewage, industrial sewage and wastewater, mix water, untreated sludge water, active sediment, industrial deposits,etc., used in construction, ditches, pumping in open-pit mining, irrigation, and drainage, etc.
The CQW Submersible Sewage Pump is mainly used for the government project, industry building, hotel, hospital, fire-fighting, mine, etc, can be used for transportation of solid particles and various long fiber of sewage, wastewater, water and urban sewage.
The CQW submersible sewage pump is a kind of submersible centrifugal sewage pump, with a non-clogging impeller, and portable design. This centrifugal marine pump is mainly used for sewage bilge, firefighting, deck-wash and emergency flood water for marine and offshore purpose.
CQW submersible sewage pump is suitable for sewage, bilge, and oily water, max liquid temp 60 C degree, a maximum diameter of the solid grain 50% of that of the pump outlet flange Max liquid temp 60 C degree, Max S.G. 1200kg/m3. The maximum diameter of the solid grain going through the CQW submersible pump has not to be larger than 50% of that of the pump outlet flange.
CQW Type Marine Magnetic Vortex Submersible Sewage Pump Technical Data
| Capacity (m³/h) | 0.5~5.4 |
| Head (m) | 20~150 |
| Speed (r/min) | 1390/2825/3450 |
| Power (kW) | 0.75-15 |
| Efficiency (η%) | 38.1-58 |
| Temperature Range | Maximum 80℃ |
CQW Type Marine Magnetic Vortex Submersible Sewage Pump Specification
| MODEL | FLOW | HEAD | POWER | SPEED | OUTLET DIA. |
| M3/H | M | KW | RPM | MM | |
| CQW65-35-50-11 | 35 | 50 | 11 | 2900 | 65 |
| CQW65-35-60-15 | 35 | 60 | 15 | 2900 | 65 |
| CQW80-65-25-7.5 | 65 | 25 | 7.5 | 2900 | 80 |
| CQW100-80-20-7.5 | 80 | 20 | 7.5 | 1450 | 100 |
| CQW100-100-15-7.5 | 100 | 15 | 7.5 | 1450 | 100 |
| CQW100-100-25-11 | 100 | 25 | 11 | 1450 | 100 |
| CQW100-100-30-15 | 100 | 30 | 15 | 1450 | 100 |
| CQW100-100-35-18.5 | 100 | 35 | 18.5 | 1450 | 100 |
| CQW125-130-15-11 | 130 | 15 | 11 | 1450 | 125 |
| CQW125-130-20-15 | 130 | 20 | 15 | 1450 | 125 |
| CQW150-130-20-11 | 130 | 20 | 11 | 1450 | 150 |
| CQW150-130-30-22 | 130 | 30 | 22 | 1450 | 150 |
| CQW150-145-9-7.5 | 145 | 9 | 7.5 | 1450 | 150 |
| CQW150-160-45-37 | 160 | 45 | 37 | 1450 | 150 |
| CQW150-180-15-15 | 180 | 15 | 15 | 1450 | 150 |
| CQW150-180-20-18.5 | 180 | 20 | 18.5 | 1450 | 150 |
| CQW150-180-25-22 | 180 | 25 | 22 | 1450 | 150 |
| CQW150-180-30-30 | 180 | 30 | 30 | 1450 | 150 |
| CQW150-200-30-37 | 200 | 30 | 37 | 1450 | 150 |
| CQW200-250-11-15 | 250 | 11 | 15 | 980 | 200 |
| CQW200-250-15-18.5 | 250 | 15 | 18.5 | 1450 | 200 |
| CQW200-250-22-30 | 250 | 22 | 30 | 1450 | 200 |
| CQW200-300-7-11 | 300 | 7 | 11 | 980 | 200 |
| CQW200-300-15-22 | 300 | 15 | 22 | 1450 | 200 |
| CQW200-350-25-37 | 350 | 25 | 37 | 1450 | 200 |
| CQW200-350-40-75 | 350 | 40 | 75 | 1450 | 200 |
| CQW200-380-28-45 | 380 | 28 | 45 | 1450 | 200 |
| CQW200-400-10-22 | 400 | 10 | 22 | 1450 | 200 |
| CQW200-400-13-30 | 400 | 13 | 30 | 1450 | 200 |
| CQW200-400-30-55 | 400 | 30 | 55 | 1450 | 200 |
| CQW250-600-9-30 | 600 | 9 | 30 | 980 | 250 |
| CQW250-600-12-37 | 600 | 12 | 37 | 1450 | 250 |
| CQW250-600-15-45 | 600 | 15 | 45 | 1450 | 250 |
| CQW250-600-20-55 | 600 | 20 | 55 | 1450 | 250 |
Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All specifications are subject to change without prior notice. All pictures shown are for illustration purposes only. Actual product may vary. Classification certification like CCS, DNV, BV, LR, NK, KR, RS shall be provided upon request.
