CuSn12P Phosphor Bronze Welding Wire
CuSn12P Phosphor Bronze Welding Wire Application
CuSn12P Phosphor Bronze Welding Wire is a solid wire for GMAW used to weld copper-tin-bronzes as well as for copper-tin-castings. Often applied to surface worn pieces as it has a good resistance to wear.
CuSn12P Phosphor Bronze Welding Wire has extremely high endurance and corrosion resistance. Suitable as mining cable for explosives in geological exploration.
Tin Bronze is a copper-tin based welding alloy containing much higher percentage of tin (approx. 12%) than Phosphor Bronze. This alloy has high strength and excellent wear and corrosion resistance due to the presence of tin in the alloy. It is suitable for both MIG and TIG welding processes and used for argon arc welding of copper-based alloys and brazing of steel.
CuSn12P Phosphor Bronze Welding Wire Physical & Mechanical Properties:
| Solids-Temperature | 825℃ |
| Density | 8.6kg/dm³ |
| Elongation | 5% |
| Liquids-Temperature | 990℃ |
| Tensile Strength | 320N/mm² |
| Brinell Hardness | 120HB |
CuSn12P Phosphor Bronze Welding Wire CHEMICAL COMPOSITE(%)
| Standard | ISO24373 | GB/T9460 | BS EN14640 | DIN 1733 |
| Class | Cu5410 | SCu5410 | Cu5410 | 2.0156 |
| Alloy | CuSn12P | CuSn12P | CuSn12P | SG-CuSn12 |
| Cu | bal. | bal. | bal. | bal. |
| Al | 0.005 | max 0.005 | 0.01 | max 0.01 |
| Fe | – | – | 0.1 | max 0.1 |
| Mn | – | – | – | – |
| Ni | – | – | – | – |
| P | 0.01-0.4 | 0.01-0.4 | 0.4 | 0.01-0.35 |
| Pb | 0.02 | max 0.02 | 0.02 | max 0.02 |
| Si | – | – | – | – |
| Sn | 11.0-13.0 | 11.0-13.0 | 11.0-13.0 | 11.0-13 |
| Zn | 0.05 | max 0.05 | 0.1 | max 0.1 |
| Other | 0.4 | max 0.4 | 0.4 | max 0.4 |
Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. For the actual specification, please check with us when order placed.
