E8015-G Low alloy steel welding electrode

Type: E (Carbon Steel Electrodes/ Low Alloy Steel Electrodes)
Material: Low carbon steel
Diameter: 2.0mm-5.0mm
Length: 300-400mm
Application: Welding of medium carbon steel structures and low alloy steel structures.

E8015-G Low alloy steel welding electrode

E8015-G Low alloy steel welding electrode Introduction

E8015-G low alloy steel welding rod is a kind of low-alloy steel electrode with low-hydrogen Natrium type coating. DCRP (Direct Current Reversed Polarity). All-position welding.

E8015-G Low alloy steel welding electrode Applications

E7015-G welding rod is suitable for welding medium-carbon steel and low-alloy steel structures like 15MnTi, 15MnV, etc.:

Packing: In carton of 20kgs/net, consisting of 8 boxes x 2.5kgs for 2.5mm, & 4 boxes x 5kgs for other sizes.

With/ without pallets (Fumigation-free pallets) upon customer’s request.

E8015-G Low Alloy Steel Welding Electrode Chemical Composition(%)

Standard & Typical Chemical Composition of Deposited Metal (%)

Chemical Composition C Mn Si S P Cr Ni Mo V Cu
Specification ≥1.00 ≥0.80 ≤0.03 ≤0.03 ≥0.30 ≥0.50 ≥0.20 ≥0.10 ≥0.20
Actual result 0.075 1.25 0.50 0.012 0.018 0.005 0.003 0.003 0.01 0.016

Standard & Typical Mechanical Properties of Deposited Metal (AW)

Test Item Postweld Condition Yield Point ReL (MPa) Tensile Strength Rm(MPa) Elongation A4(%) Akv Value (J)
Specification PWHT ≥460 ≥550 ≥19
Actual Result 620℃X1h 480 590 24 -40℃ 100

Size and Current (DC +)

Dia.(mm) 2.5 3.2 4.0 5.0
Length(mm) 300 350 400 400
Current(A) 60-90 80-110 130-170 160-200

Classification certification like CCS, DNV, BV, LR, NK, KR, RS shall be provided upon request.

Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. For the actual specification, please check with us when order placed.
