Marine Rubber Tugboat Bow Fender
Marine Rubber Tugboat Bow Fender Introduction
The Marine Rubber Tugboat Bow Fender is mainly used for the harbor or for the tugboat, install for tugboat’s rail and stern, working for push, drag etc With the excellent overall performance, high quality, easy for installation. The length can production for 3m-26m, other sizes also can be customized.
Large Cylindrical Tugboat Fenders are often used as the primary pushing fenders on the bow or stern of modern tugs. Their round shape is ideal for working with large bow flares (like container ships), but are equally good for pushing flat-sided vessels.
The Marine Tugboat fender can be supplied with certification from any of the major classification societies.
Marine Rubber Tugboat Bow Fender Drawing
Marine Rubber Tugboat Bow Fender Drawing
Marine Rubber Tugboat Bow Fender Specification
| Type | ФD | Фd | Фd1 | b | c | I |
| mm | mm | mm | mm | mm | mm | |
| Ф300xФ150xL | 300 | 150 | 50 | 25 | ||
| Ф300xФ100xL | 300 | 100 | 50 | 25 | ||
| Ф400xФ200xL | 400 | 200 | 50 | 35 | 300 | |
| Ф400xФ150xL | 400 | 150 | 100 | 50 | 35 | |
| Ф400xФ100xL | 400 | 100 | 50 | 35 | ||
| Ф500xФ250xL | 500 | 250 | 60 | 40 | 350 | |
| Ф500xФ220xL | 500 | 220 | 100 | 60 | 40 | 350 |
| Ф500xФ200xL | 500 | 200 | 100 | 60 | 40 | 350 |
| Ф500xФ150xL | 500 | 150 | 100 | 60 | 40 | |
| Ф600xФ300xL | 600 | 300 | 60 | 35 | 400 | |
| Ф600xФ250xL | 600 | 250 | 100 | 60 | 50 | 400 |
| Ф600xФ220xL | 600 | 220 | 100 | 60 | 50 | 400 |
| Ф600xФ200xL | 600 | 200 | 100 | 60 | 50 | 400 |
| Ф700xФ350xL | 700 | 350 | 60 | 50 | 450 | |
| Ф700xФ300xL | 700 | 300 | 100 | 60 | 50 | 400 |
| Ф700xФ250xL | 700 | 250 | 100 | 60 | 50 | 400 |
| Ф700xФ220xL | 700 | 220 | 100 | 60 | 50 | 400 |
| Ф800xФ400xL | 800 | 400 | 70 | 50 | 450 | |
| Ф800xФ350xL | 800 | 350 | 100 | 70 | 60 | 450 |
| Ф800xФ300xL | 800 | 300 | 100 | 70 | 60 | 450 |
| Ф900xФ450xL | 900 | 450 | 70 | 50 | 500 | |
| Ф900xФ400xL | 900 | 400 | 100 | 70 | 50 | 500 |
| Ф900xФ350xL | 900 | 350 | 100 | 70 | 50 | 500 |
Other spec and Sizes can be Manufactured upon users’ request.
L=3000 – 26000mm
Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All specifications are subject to change without prior notice. All pictures shown are for illustration purposes only. Actual product may vary. Classification certification like CCS, DNV, BV, LR, NK, KR, RS shall be provided upon request.
