20ft T50 Liquid chlorine Tank Container
20ft T50 Liquid chlorine Tank Container Introduction
The Liquid chlorine Tank Container is designed to comply with the requirements of IMDG Code, aiming at transportation and stock Liquid chlorine. This Liquid chlorine Tank is made of stainless steel or carbon steel with lining.
Standard: IMDG, RID/ADR, ASME VII DIV2, CFR 48, USDOT (BYSP), TIR, UIC, CSC, TC, UKDFT, FRA
Type: Vertically Mounted & Horizontal Mounted
Design Temperature:-40 degree Celsius to +55 degree Celsius
Certificate: CSC certificate like GL/LR/BV/ABS
All tanks are of the highest quality design and construction and conform strictly to the latest international approvals.
20ft T50 Liquid chlorine Tank Container Specification
| Dimensions | 20’*8’*8’6” |
| Tank Capacity | 25,000 Litres |
| Tare Weight | 7,500 kg |
| MGW | 34,000 kg |
| Working Pressure | 22.8Bar |
| Test Pressure | 28.6 Bar |
| Shell Material | Corten Stel-EN10028/SA-299 Shell-16.4mm minimum Head-15.2mm minimum |
| Sunshine Material | 2mm marine grade aluminum |
| Baffles | Provision only |
| Manhole Cover | Dome end-dished to allow fitting of a level gauge |
| Relief Valve | 1×3” with provision for bursting disc and manometer |
| Valve Cabinet | Rear end of the tank with aluminum lockable hinged door Cabinet holds all valves, pressure gauge, and thermometer |
| Approvals | RID/ADR-US DOT-IMDG-ISO CSC-TC-UIC |
Please note that the above specifications are “general specifications” that pertain to the majority of our products. These specifications should only be used for general, informational purposes. The measurement/size of the goods delivered may be different from the data in the above table, please check with us when order placed.
