CuNi10 Copper-Nickel Alloy Welding Wire

BS EN Specification: BS EN14640 CuNi10
ISO24373 Specification: CuNi10
DIN 1733 Specification: SG-CuNi10Fe
Size 0.8㎜ 0.9㎜ 1.0㎜ 1.2㎜ 1.6㎜ 2.0㎜
Applications: CuNi10 Welding wire is especially suitable for the welding and hard facing copper-nickel alloys such as machinery, desalting of seawater, ship-building, oil refinery, and food processing industries.

CuNi10 Copper-Nickel Welding Wire

CuNi10 Copper-Nickel Welding Wire Application

Due to high tensile strength and increased resistivity values, CuNi10 are the first choice for applications as resistance wires. With the different nickel amount in this product range, the characteristics of the wire can be chosen according to your requirements. Copper-nickel alloy wires are available as bare wire, or enameled wire with any insulation and self-bonding enamel. Furthermore, wire made of enameled copper-nickel alloy wire are available.

Copper Nickle Welding wire is especially good for seawater corrosion resistance.Particularly suitable for the welding and hard facing copper-nickel alloys such as machinery, desalting of sea water, ship-building, oil refinery, and food processing industries.

This alloy presents the particularity to be very malleable, to have a good resistance to corrosion until temperatures of 400°C and a good solderability. Ideal applications areas are all types of resistances used at low temperature.

CuNi10 Copper-Nickel Welding Wire Features

Higher resistance than copper
High tensile strength
Good bending proof performance

CuNi10 Copper-Nickel Welding Wire Physical and mechanical data

Solids-Temperature 1100℃
Density 8.9kg/dm³
Elongation 34%
Liquids-Temperature 1145℃
Tensile Strength 300N/mm²
Brinell Hardness 80HB

CuNi10 Copper-Nickel Welding Wire CHEMICAL COMPOSITION(%)

Standard ISO24373 GB/T9460 BS EN14640 DIN 1733
Class Cu7061 SCu7061 Cu7061 2.0873
Alloy CuNi10 CuNi10 CuNi10 SG-CuNi10Fe
Cu bal. bal. bal. bal.
Fe 0.5-2.0 0.5-2.0 0.5-2.0 1.0-2.0
Mn 0.5-1.5 0.5-1.5 0.5-1.5 0.5-1.5
Ni 9.0-11 9.0-11 9.0-11 9.0-11
P 0.02 max 0.02 0.02 max 0.02
Pb 0.02 max 0.02 0.02 max 0.02
Si 0.2 max 0.2 0.2 max 0.2
C 0.05 0.05 max 0.05
Ti 0.1-0.5 0.1-0.5 0.1-0.5 0.2-0.5
S 0.02 max 0.02 0.02 max 0.015
Other 0.4 max 0.4 0.4 max 0.4

Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. For the actual specification, please check with us when you place the order.
