RY Series Thermal Oil Lubrication Pump
RY Series Thermal Oil Lubrication Pump Application
The RY Series Thermal Oil Lubrication Pump is a kind of centrifugal pump. It is designed to handle thermal oil up to 350°C temperature. RY series pumps are of centrifugal, single stage, horizontal shaft type. Self-balancing impeller by rear impeller blades. No cooling of the seal chamber required.
Generally, the pump is driven by an electric motor coupled to the pump by means of an elastic coupling. It is possible to fit a flexible spacer coupling so as to dismantle the complete pump support without removing pump casing and motor from the base plate. The coupling is protected by a cover, so as to prevent external intrusion.
RY Series Thermal Oil Lubrication Pump Specification
| Model | Capacity | Head | Speed | Power(KW) | Efficiency | NPSH | Motor model | |
| (m3/h) | (m) | (r/min) | Shaft | Motor | (%) | (m) | ||
| RY26-20-100 | 4.5 | 15 | 2825 | 0.45 | 0.75 | 40 | 0.8 | Y801-2 |
| RY50-32-150 | 8 | 22 | 2840 | 1 | 1.5 | 42 | 1.6 | Y90S-2 |
| RY50-32-160 | 10 | 25 | 2840 | 1.5 | 2.2 | 42 | 1.8 | Y90L-2 |
| RY65-40-160 | 12.5 | 25 | 2880 | 2.5 | 3 | 45 | 2.2 | Y100L-2 |
| RY50-50-170 | 12.5 | 32 | 2890 | 3.2 | 4 | 45 | 2.5 | Y112M-2 |
| RY65-50-180 | 32 | 32 | 2900 | 4.5 | 5.5 | 52 | 2.7 | Y132S1-2 |
| RY65-50-170 | 40 | 25 | 2900 | 4.5 | 5.5 | 52 | 2.7 | Y13-22S2-2 |
| RY80-50-180 | 40 | 40 | 2900 | 6.7 | 7.5 | 63 | 3.1 | Y132S2-2 |
| RY80-50-170 | 60 | 20 | 2900 | 6.7 | 7.5 | 63 | 3.1 | Y160M-2 |
| RY100-65-190 | 60 | 38 | 2930 | 9.2 | 11 | 68 | 3.9 | Y160M1-2 |
| RY100-65-200 | 80 | 40 | 2930 | 12.5 | 15 | 70 | 3.5 | Y160M1-2 |
| RY100-65-220 | 58 | 50 | 2930 | 12.5 | 15 | 68 | 3.5 | Y160M1-2 |
| RY100-65-230 | 100 | 55 | 2940 | 19.5 | 22 | 70 | 3.6 | Y180M-2 |
| RY125-100-190 | 155 | 30 | 2940 | 20 | 22 | 72 | 3.6 | Y180M-2 |
| RY100-65-240 | 100 | 70 | 2950 | 25.5 | 30 | 69.8 | 4.1 | Y200L1-2 |
| RY100-65-257 | 100 | 80 | 2950 | 32.5 | 37 | 67 | 3.6 | Y200L2-2 |
| RY125-100-2200 | 160 | 45 | 2950 | 25.5 | 37 | 75.2 | 3.6 | Y200L2-2 |
| RY125-80-250 | 160 | 60 | 2970 | 35.5 | 45 | 74.2 | 5 | Y225M-2 |
| RY125-100-250 | 200 | 60 | 2970 | 42.8 | 55 | 76.8 | 6 | Y250M-2 |
| RY125-100-257 | 260 | 70 | 2970 | 64.3 | 75 | 77.1 | 6.8 | Y280S-2 |
| RY125-100-260 | 300 | 70 | 2970 | 75.3 | 90 | 78.2 | 8 | Y280S1-2 |
| RY125-100-270 | 220 | 85 | 2970 | 68 | 90 | 76 | 6 | Y280S1-2 |
| RY150-l25-270A | 340 | 76 | 2970 | 89.5 | 110 | 78.6 | 8.5 | Y315S-2 |
| RY150-125-270 | 400 | 78 | 2970 | 106 | 132 | 80.6 | 9.8 | Y315M1-2 |
Please note that the above specifications are “general specifications” that pertain to the majority of our production. These specifications should only be used for general, informational purposes. Subject to change without prior notice. For the actual specification, please check with us when order placed. Classification certification like CCS, DNV, BV, LR, NK, KR, RS shall be provided upon request.
